Window handle oval knob bronze antique for tilt and turn window

Window handle oval knob bronze antique for tilt and turn window. A window handle in classic style made of solid brass and with a bronze antique color. The tilt and turn system fits standard tilt and turn windows. Often windows come with simple and modern window handles that do not match the rest of the interior. With this classic window handle can also make the window as one with the rest of the classic interior.

Dimensions of the window handle oval knob bronze antique for tilt and turn window

The knob on the system is 78mm long and 36mm wide. The oval knob handle comes forward approximately 54mm. The holes for the two bolts have a standard center distance of 43mm and a hole size of 6mm. This set isfor window systems with a square hole size of 7mm. The pin of the system protrudes 35mm into the window which is the standard. However, there should be at least 40mm space relative to the center of the window system. Otherwise the knob cannot rotate fully.

By default, the system is secured with two M5 bolts. The depth of the tilt and turn system in the window determines which length bolt is needed. Standard bolts of the correct length are usually supplied with a tilt-turn window. Therefore no bolts are included with this handle.
