Drawer guide plastic white 350mm x 16mm x 11mm Häfele drawer rail per pair zs

Drawer guide plastic white 350mm x 16mm x 11mm Häfele drawer rail per pair. A pair of drawer slides for surface mounting made of plastic in the color white. The plastic has a very smooth finish so they guide well. These guides can be mounted on the side of a piece of furniture or kitchen over which the drawer runs. In most cases, a slot is milled on the side just a fraction larger than the height of the drawer runner (16mm or slightly larger). This prevents the drawer from falling down easily when extended. Optionally, these drawer runners can also be mounted under a drawer.

In addition, these runners can also be used to run up plastic trays. For example, a storage cabinet for toys or hardware can be made with several bins on top of each other. To prevent the bins from falling down easily as soon as they are pulled out too far, two can be mounted on top of each other if necessary.

Dimensions and use of the drawer guideplastic white 350mm

It has an overall length of 350mm, a height of 16mm (15.7mm) and a thickness of 11mm. The maximum weight per set is about 25kg. At three points of the ladder runner are fixed, plastic dowels that drop into pre-drilled holes in the sidewall. These dowels have a length of 7mm and a diameter of 8.2mm. The holes for these dowels can be drilled with a diameter of 8mm so that they fall in with slight resistance. If necessary, additional glue can be used for assembly.

Then the drawer guide can be secured with a screw so that it stays neatly against the side wall. The screw hole has a diameter of 4mm and is countersunk. The countersunk part ends with a diameter of 8mm which can be the maximum diameter of the screw head. With a larger head, it may get in the way of proper guiding. The plastic drawer slides are supplied without screws.
